Products

Maul Technology sets standards of customer service few can match. Our commitment to be customer responsive is combined with a working ability to be flexible in every element of the business, making customer service our key quality standard.

Long experienced in the design and manufacture of IS machines and associated glass forming and control equipment, we cover the entire range of production needs for IS machine operation. Our production facilities will manufacture and assemble any size machine and number of sections.

From a strong base of experience and technical ability, we have developed levels of working cooperation to ensure every contract is approached with the aim of designing and engineering, the best possible solution dedicated to the specific customer application.



M-2000

Machine Drive and Electronic Pusher fully integrated with the IS Electronic Timing System:

  • All products operate as one system with single point control via Hot End, Master or Hand Held Terminals
  • System computers connected via a fiber optic local area network for noise immunity and reliability
  • Touch Screen Operator Interface for ease of use
  • Job history stores all user setup parameters controlled by the Maul Integrated System
  • Battery backed memory retains setup parameters and data during power outages
  • Comprehensive alarm system with time and date stamps and long term disk log
  • Graphic displays for production reports, machine timing, pusher profiles, pusher retract /  extend timing and speed
  • Programmable hot ware reject system operates manually or with Swab, Cold Mold and Special Cycles and Gob Enable
  • On-Line Help system
  • Internal diagnostics for troubleshooting and monitoring critical system functions
  • User programmable security for every system function
  • Includes all control terminals necessary - no additional personal computers or other equipment necessary
Hot End Terminal
Operator Controls

Screen Shot Sample
Shop Master Terminal

M-2000 systems have an excellent track record of reliability with many controllers having run for several years without incurring a failure. This is the kind of  "up time" required by 24/7 operations.

Maul Technology has satisfied customers around the globe that can attest to the integrity of its wide range of products and services. We are very conscious of the need to build and maintain close working relationships with its customer base. We feel the best way to achieve long lasting partnerships with our customers is to provide superior products and excellent service. This philosophy has been applied to the M-2000 product line. These systems are tools, very large tools, which must enable glass manufacturers to produce higher quality ware more efficiently.

We are constantly looking to improve these products by carefully considering customer requests for the incorporation of new features that will enhance their production processes. New software releases are offered on a continuing basis and as new technology is utilized, additional performance improvements can be realized from the installation of hardware upgrades that are made available from time to time.

M-2000 Brochure (pdf)

Major Feature Listing (pdf)



[ return to top ]



Mechanisms

Chart of
E, EF & F Mechanisms

View Chart



Anti-Backlash Neckring Mechanism



Hardened drive gears are available in all sizes. Perfect tolerances are maintained on the hardened bushing and guide rods. Interchangeable with other mechanisms. Positive latch feature and constant grip nuts are available.

Detailed Spec Sheet (pdf)



New and improved Anti-Backlash Neckring with Needle bearings on the main shaft, seals in the end bearings and split gear.

Detailed Spec Sheet (pdf)



Constant Cushion Invert Mechanism



We manufacture a complete range of Constant Cushion Invert mechanisms to suit all IS machine sizes.

Detailed Spec Sheet (pdf)

Sample of new spec sheet for Gary (pdf)

Sample of PDF at 300 (pdf)

Sample of PDF at 600 (pdf)

Sample of PDF at 1200 (pdf)



Constant Cushion Take Out Mechanism



We manufacture a complete range of Constant Cushion Take Out mechanisms to suit all IS machine sizes.

Detailed Spec Sheet (pdf)



Electronic Valve Blocks



We manufacture a full range of Electro-Pneumatic Valve blocks to operate in conjunction with a wide variety of Electronic Timing Systems. Standard valve blocks can be customized to suit individual specification.

Detailed Spec Sheet (pdf)



Heavy Duty Baffle Mechanism for Expanded Center Machines



This derivative of our Heavy Duty Baffle Mechanism has been developed in answer to customer demands.

  • Direct Operation - speed control from the valve block.
  • Remote cushioning piping internal in the section frame and needle valve control to the rear of the blank bracket.
  • The need for all external tubing to the mechanism is removed.

Detailed Spec Sheet (pdf)



Heavy Duty Blowhead Mechanism



Available in standard or short stroke and is fitted with a solid piston rod for use with external final blow.

Each mechanism contains new components together with existing sub assemblies which have proven themselves in extensive field trials.

Detailed Spec Sheet (pdf)



Designed for use on "E" and 5" machines operating single or double gob and 6" and 6 1/2" machine operating single, double or triple gob. The Final Blow Trip Valve, Junction Block and Sleeve Bushing have been eliminated from the Cylinder Head.

These mechanisms are equipped with solid piston rods and must be operated in conjunction with External Final Blow.

Detailed Spec Sheet (pdf)



Heavy Duty Funnel Mechanism



For use on a range of IS Machines. The Heavy Duty Funnel Mechanism is designed for use with centering rings and contains new components together with existing sub assemblies which have proven themselves in extensive field trials.

Detailed Spec Sheet (pdf)



High Performance Blank Mold Supporting Assembly for 5" EF Machines



A high performance Blank Mold Supporting Assembly manufactured from a robust, well proven casting and fitted with an anti-deflection assembly.

Detailed Spec Sheet (pdf)



Linkage in Oil



Maul Technology Linkage in Oil yields increased clamping force on both Molds and Blanks as well as prolonged operating life. The revised linkage design provides an improved mechanical advantage resulting in greater closing forces.

Detailed Spec Sheet (pdf)



Quick-Change Plunger Mechanism



Replacement time of the Quick-Change Plunger Mechanism is significantly reduced from hours to just a few minutes.

The need to shut down adjacent operating sections has been eliminated.

The need to remove blank bracket, wind nozzle bases and wind build-up has been eliminated as well.

Detailed Spec Sheet (pdf)

Detailed Technical Features (pdf)

[ return to top ]



Variables













[ return to top ]

On-Site Service

Our on-site service teams are experienced and arrive well equipped to align, set up and make whatever final adjustments are needed to maximize machine performance. They will provide whatever level of service you require, from relatively minor repairs to full scale installation and commissioning projects along with any subsequent service and maintenance needs thereafter.

We will provide a full service team or an individual service engineer as required, well supported by substantial stock holding of spare parts and a high quality manufacturing service of spare parts which are universal in their suitability for use on all major IS machines.

We take customer service to the customer with complete facilities for every form of on-site mechanical and electrical work. Teams of highly skilled service engineers are well equipped and quick in response for every customer operating need.

Machines can be quickly assessed and estimated for repair with detailed lists of parts. Modular sections and mechanisms can be refurbished and refitted or replaced with new components. Machine upgrading can substantially update existing installations to bring performance and response in line with the recent advances of control technology, with electronic timing, electronic conveyors and servo-controlled mechanisms.

Any form of machine process and configuration change can be engineered, together with on-site mechanism repair.



[ return to top ]

Spare Parts











[ return to top ]
